LABORATORINIS MAITINTUVAS UT-P3313-TFL-II UNI-T

The UT-P3313-TFL-II laboratory power supply allows you to generate a constant voltage or current with strictly defined parameters. The device can work in one of two modes: as a source of constant voltage or as a source of constant current.

Output voltage range of the power adapter:	0 V ... 30 V
Power supply output current range:	0 A ... 3 A
Output power:	96 W
Setting resolution:	Voltage : 10 mV @ 25 °C ± 5 °C Current : 1 mA @ 25 °C ± 5 °C
Setting accuracy:	Voltage : < 0.5 % + 20 mV @ 20 Hz ... 20 MHz Current : < 0.5 % + 10 mA @ 20 Hz ... 20 MHz
Ripple and noise:	Voltage : ≤ 2 mV RMS Current : ≤ 3 mA RMS
Temperature coefficient:	Voltage : ≤ 300 ppm/°C Current : ≤ 300 ppm/°C
Response time:	< 100 µs
Number of outputs:	1
Display:	LED display - Double
Power supply:	230 V AC / 110 V AC - selectable by switch
Operation temp. / Relative humidity:	0 °C ... 40 °C / ≤ 85 %
Weight:	3.3 kg
Dimensions:	255  x 165  x 105 mm
Manufacturer / Brand:	UNI-T
Guarantee:	2 years
