MARŠRUTIZATORIUS MODEM 4G LTE CAT. 6 RUTX09 Dual SIM Teltonika

The RUTX09 wired router allows to connect the LAN network to the Internet via a built-in 4G modem. The device is equipped with 4 Ethernet ports (3 x LAN + WAN), 1 configurable digital input/output, a USB port, 2 SIM card slots and SMA connectors for LTE and GNSS (Global Navigation Satellite Systems) antennas. The device is compatible with IoT (Internet of Things) technology.

The router is managed by the RutOS operating system and supports industrial protocols such as Modbus, DLMS, DNP3, OPC UA, and is compatible with the RMS management system, enabling efficient remote and local management of the device. The Teltonika RMS application is dedicated to management.

The Teltonika RUTX09 router has a 4-pin industrial power socket and supports a wide range of power supply voltages.

Frequency range:	LTE / GSM : 698  ... 960 MHz, 1710  ... 2690 MHz , GNSS : 1575.42  ... 1602 MHz
Antenna type:	2 x Omnidirectional antenna 4G LTE - 3 dBi (SMA connector), 1 x Omnidirectional antenna GNSS - 28 dB (SMA connector)
Standards:	LTE Cat. 6, 3G WCDMA, GNSS : GPS, GLONASS, BeiDou, Galileo, QZSS
Baud rates:	LTE : 300 / 42 Mbps (4G / 3G)
LAN ports:	3  x 10/100/1000 Mbps
WAN interface:	1  x 10/100/1000 Mbps
Transmitter power:	≤ 23 dBm @ 4G+ LTE ≤ 24 dBm @ 3G WCDMA
LED indicators:	Power WAN : SIM 1, SIM 2, ETH 2G, 3G, 4G, 5 x Signal indicator 4 x Link/Act : 3 x LAN + WAN
Network type:	4G LTE-FDD: B1/3/5/7/8/20/28/32 4G TDD-LTE B38/B40/B41 3G WCDMA: B1/3/5/8
LTE:
QSS:
WDS:
SIM card slot:	2 x Mini SIM – 2FF
DDNS:	Support > 25
DHCP server:
USB port:	USB 2.0
Protections:	WPA2-Enterprise - PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE, AES-CCMP, TKIP, EAP-TLS Auto Cipher modes Client separation SSID hiding Firewall Protection against DDOS, SYN, SSH, HTTP/HTTPS attacks Configurable, independent data limits for each SIM card Black list / White list MAC addresses filtering Protection against the effects of reverse polarity power connection Overvoltage protection
Management interface:	Web browser, Teltonika RMS application, SMS
Default IP address:	192.168.1.1
Operating system:	RutOS (Linux OS based)
Firmware update:
Main features:	Dual SIM Compliance with the Modbus, DLMS, DNP3, OPC UA protocol MDI/MDI-X auto detection feature - auto detecting the data transmission mode Static / dynamic routing Support for VoIP technology, Ability to work as a Hotspot View topology and network status WMM support (QoS mechanism of the 802.11e standard) DHCP Relay support VLAN support VPN networks: IPsec VPN, L2TP VPN, PPTP VPN, Open VPN Compliance with the MQTT protocol SNMP v1/v2/v3/Trap WAN Connection Backup - thanks to the fully functional WAN / LAN port, you can use various types of backup connections, including cable, fiber and DSL modems Support for IoT (Internet of Things) systems, Configuration using the Teltonika RMS application Durable aluminum housing Shock-proof Industrial wide temperature design. RESET button USB 2.0 port - possibility to connect external HDD, flash drive, additional modem, printer, USB-serial adapter 4-pin industrial power socket, Wide range of supported supply voltages, 1 digital input / output - ability to set certain I/O conditions to initiate event Grounding "Index of Protection" : IP30 Ethernet cable included
Power supply:	12 V DC / 1.5 A (power adapter included) 9 ... 50 V DC 9 ... 50 V DC - Passive PoE, Powering from LAN1
Power consumption:	≤ 9 W
Operation temp:	-40 °C ... 75 °C
Permissible relative humidity:	10 % ... 90 % (non-condensing)
Weight:	0.46 kg
Dimensions:	115  x 103  x 44 mm
Manufacturer / Brand:	Teltonika
Guarantee:	2 years
